Home > Products >> RF Terminator & Dummy Load >> 10W RF Terminator Dummy Load

  • 10W SMA RF dummy load terminator 6GHz 8Ghz 12GHz 18GHz 26.5GHz 50ohm

    • 10W SMA RF dummy load terminator 6GHz 8Ghz 12GHz 18GHz 26.5GHz 50ohm

    TWTS-10-6G
    Frequency 6GHz and up to 18GHz optional
    SMA,N,BNC,4.3-10 connector optional
    Factory supply with fast delivery
    Welcome to send inquiry

    Inquire Now
    • Product Description

    Dummy Load is a device used to simulate an electrical load during testing. In an RF System a dummy load is used to simulate an antenna. By using a dummy load instead of an actual antenna, the transceiver can be tested and configured without radiating radio waves.


    10W SMA RF Terminator, dummy load 6GHz 50ohm
    Norminal Impendance50ohm
    Frequency rangeDC-6GHz
    VSWR

    6GHz≤1.2
    18GHz≤1.3
    26.5GHz≤1.35

    Power rating10W
    Temperature range-55℃ to 125℃
    Tags: 10W SMA dummy load , 10W SMA terminator, 10W SMA RF Load, 10W load termination
