Professional Factory service
OEM&ODM Service Support
Fast Delivery with great service
Welcome to send any inquiry and we will do our best to support
| Model No. | Frequency (GHz) | Band Width (MHz) | Insertion Loss (dB.Max) | Isolation (dB.Min) | VSWR (Max) | Operating Temperature (℃) | Power (W.Max) | Reverse | Size L*W*H m) | Connector Type |
| TW101F | 1-2 | Full | 0.7 | 15 | 1.5 | 0~+60 | 60 | 10~50 | 64*66*26 | SMA Or N |
| TW201-B2 | 1.35-2.7 | Full | 0.6 | 17 | 1.35 | 0~+60 | 30 | 20 | 50.8*49.5*19 | SMA |
| TW201D | 2-3 | Full | 0.4 | 20 | 1.25 | -10~+60 | 30 | 20 | 28*30*18 | SMA Or N |
| TW301B | 2-4 | Full | 0.6 | 18 | 1.4 | -30~+70 | 30 | 20 | 32*34*18 | SMA Or N |
| TW401AS-26 | 2-6 | Full | 1.1 | 15 | 1.5 | 0~+60 | 20 | 10 | 60*42*19 | SMA |
| TW401AS-28 | 2-8 | Full | 1.5 | 12 | 1.8 | 0~+60 | ||||
| TW402-46 | 4-6 | Full | 0.5 | 18 | 1.3 | -40~+85 | 10 | 10 | 16*23*9 | TAB |
| TW501B | 4-8 | Full | 0.6 | 18 | 1.3 | -30~+70 | 10 | 10 | 20*32*13 | SMA |
| TW601C | 4-8 | Full | 0.4 | 18 | 1.35 | -30~+70 | 20 | 10 | 19*19*13 | SMA |
| 5-10 | Full | 0.5 | 16 | 1.4 | ||||||
| TW601D | 3-6 | Full | 0.5 | 18 | 1.3 | -20~+60 | 20 | 10 | 25*25*15 | SMA |
| TW701B | 6-12 | Full | 0.6 | 16 | 1.4 | -30~+70 | 10 | 10 | 16*26*13 | SMA |
| TW801A | 8-12 | Full | 0.5 | 20 | 1.25 | -40~+85 | 10 | 5 | 12*20*13 | SMA |
| TW801F | 7-13 | Full | 0.5 | 17 | 1.3 | -30~+70 | 10 | 5 | 12*20*13 | SMA |
| 10-15 | Full | 0.5 | 20 | 1.25 | ||||||
| 12-18 | Full | 0.5 | 20 | 1.25 | ||||||
| TW1201 | 10-18 | Full | 0.7 | 17 | 1.35 | -30~+70 | 10 | 5 | 15*23*13 | SMA |
| 8-18 | Full | 0.8 | 16 | 1.45 | ||||||
| TW1201B | 6-18 | Full | 1.5 | 10 | 1.8 | -30~+70 | 10 | 5 | 12.7*18.5*8.3 | TAB |
| TW1201C | 6-18 | Full | 1.5 | 12 | 1.8 | -30~+70 | 10 | 5 | 19*27*13 | SMA |
