Frequency covers 80MHz~40GHz
Factory service with Fast lead time
OEM&ODM Service support
| Model No. | Frequency (GHz) | Band Width (MHz) | Insertion Loss (dB.Max) | Isolation (dB.Min) | VSWR (Max) | Operating Temperature (℃) | Average Power (W.Max) | Peak Power (W) | Size L*W*H (mm) | Connector Type |
| TW0101PW-X | 0.1~0.4 | 20% | 0.4 | 23 | 1.2 | -20~+85 | 1000`1500 | 15000 | 116*149*36 | L27 Or L29 |
| TW0101F-P | 0.15~1.0 | 15% | 0.4 | 20 | 1.25 | -20~+85 | 800~1200 | 10000 | 80*120*35 | N Or L29 |
| TW0601P1-X | 0.3~0.6 | 20% | 0.4 | 20 | 1.25 | -30~+85 | 600~1000 | 8000 | 60*100*35 | N Or L29 |
| 0.617-0.894 | Full | 0.5 | 17 | 1.35 | ||||||
| 0.698-0.96 | Full | 0.4 | 18 | 1.3 | ||||||
| 1.0~3.0 | 20% | 0.4 | 20 | 1.25 | ||||||
| TW201GP-X | 0.3-0.4 | Full | 0.4 | 18 | 1.25 | -10~+70 | 500 | 4000 | 52*88*28 | N |
| 0.4-0.52 | Full | 0.4 | 23 | 1.25 | ||||||
| 0.6-0.8 | Full | 0.5 | 20 | 1.25 | -20~+85 | |||||
| 0.698-0.96 | Full | 0.5 | 18 | 1.3 | ||||||
| 1.0~3.0 | 15% | 0.4 | 20 | 1.25 | ||||||
| TW201FP-X | 1.5~4.0 | 40% | 0.4 | 21 | 1.2 | -20~+75 | 350 | 3000 | 54*89*35 | N |
| TW301BP-X | 2.0~6.0 | 200 | 0.3 | 23 | 1.2 | -20~+75 | 250 | 2000 | 34*37.5*42.4 | N |
| 30% | 0.4 | 20 | 1.25 | |||||||
| TW102F-P | 2.0-6.0 | 10% | 0.4 | 20 | 1.25 | -30~+75 | 100 | 800 | 19*25.4*10 | TAB |
| TW702D1-P | 4.5-9.0 | 10% | 0.4 | 20 | 1.25 | -30~+75 | 50 | 500 | 12*20*9 | TAB |
| TW401FP | 4.5~9.0 | 10% | 0.4 | 20 | 1.2 | -30~+75 | 50 | 500 | 16*25.5*14 | SMA |
| TW801A-P | 9.0~18.0 | 10% | 0.4 | 20 | 1.25 | -40~+75 | 30 | 300 | 17*27*8.8 | SMA |
New products always update under line and not always online in time, if you can not find what you want above.please contact us directly.we will reply very fast.
