2.92mm to SMP Millimeter Wave Adapter 40GHz 50ohm

2.92mm male to SMP female

2.92mm male to SMP male

2.92mm female to SMP female
2.92mm female to SMP male

2.92mm Precision coaxial connector for microwave applications.the maximum frequency is 40GHz.

•Design in accordance with: IEEE Std 287 TM -2007

Standard materials and finish

•Center conductor:beryllium copper，gold plated

•Insulator:PEI

•Outer conductor:Stainless steel,Passivated

Electrical Characteristics

•Characteristic Impedance:50Ω

•Frequency range:DC-40GHz

•VSWR:1.25:1 max

•Insulation resistance: 5000MΩmin

•Test voltage:1000V

Mechanical

•Coupling torque:1.69N• max

•Mating cycles: 500cycles min

Environmental

•Temperature range: -55℃～+155℃
