  • NEX10 Male to 4.3-10 Female RF Adapter Low PIM -160dBc

    • NEX10 Male to 4.3-10 Female RF Adapter Low PIM -160dBc

    Factory supply with fast delivery
    Welcome to send inquiry

    Inquire Now Next Product
    • Product Description

    NEX10 Series all available，For more details pls contact us

    NEX10 M/F to SMA M/F
    NEX10 M/F to N M/F
    NEX10 M/F to 3.5mm M/F

    NEX10 M/F to 4.3-10 M/F
    NEX10 M/F to 7/16 DIN M/F

    Material & Finishing

    1.Center conductor : Phosphor Bronze,Silver Plating

    2.Insulators : PTFE

    3.Body: Brass,Ternary alloy Plating

    4.Other: Brass, Ternary alloy Plating Phosphor Bronze, Silver Plating beryllium-copper,Silver Plating

    5.Gasket: Silicone Rubber

    Electrical Data

    1.Characteristic Impedance: 50 Ohms

    2.Frequency: 0~6GHz

    3.VSWR: 1.1(DC-3GHz)

    4.Dielectric Resistance: ≥5000MΩ

    5.PIM3: ≤-160dBc

    Factory service NEX10 Adaptor SMA/3.5mm/N/4.3-10 RF Adaptor

    Tags: NEX10 to 4.3-10 Adapter, NEX10 to 4.3/10 Adapter, NEX10 Coaxial Adapter, NEX10 RF Adapter, NEX10 Adapter low PIM, NEX10 RF Adapter, NEX10 male Adapter, NEX10 Female Adapter, NEX10 Adapter 6GHz
