| Model No. | Frequency Range (GHz) | Insertion Loss (db.Max) | VSWR (Max) | Operating Temperature (℃) | Average Power (W) | Wageguide Type | Connector Type |
| TWG22 | 1.7-2.6 | 0.2 | 1.2 | -55~+85 | 100 | WR430 | SMA/N |
| TWG26 | 2.2-2.3 | 0.2 | 1.2 | -55~+85 | 100 | WR340 | SMA/N |
| TWG32 | 2.6-3.95 | 0.15 | 1.25 | -55~+85 | 100 | WR284 | SMA/N |
| TWG40 | 3.3-4.9 | 0.3 | 1.2 | -55~+85 | 100 | WR229 | SMA/N |
| TWG48 | 3.95-5.85 | 0.15 | 1.2 | -55~+85 | 100 | WR187 | SMA/N |
| TWG58 | 4.9-7.05 | 0.15 | 1.2 | -55~+85 | 100 | WR159 | SMA/N |
| TWG70 | 5.85-8.2 | 0.15 | 1.25 | -55~+85 | 50 | WR137 | SMA/N |
| TWG84 | 7.05-10.0 | 0.15 | 1.2 | -55~+85 | 50 | WR112 | SMA/N |
| TWG100 | 8.2-12.4 | 0.15 | 1.2 | -55~+85 | 50 | WR90 | SMA/N |
| TWG120 | 10.0-15.0 | 0.15 | 1.2 | -55~+85 | 50 | WR75 | SMA/N |
| TWG140 | 12.4-18.0 | 0.2 | 1.2 | -55~+85 | 50 | WR62 | SMA/N |
| TWG180 | 15.0-22.0 | 0.2 | 1.2 | -55~+85 | 50 | WR51 | SMA |
| TWG220 | 18.0-26.5 | 0.2 | 1.25 | -55~+85 | 50 | WR42 | SMA Or 2.92mm |
| TWG260 | 22.0-33.0 | 0.2 | 1.2 | -55~+85 | 50 | WR34 | 2.92mm |
| TWG320 | 26.5-40.0 | 0.2 | 1.25 | -55~+85 | 50 | WR28 | 2.92mm Or 2.4mm |
| TWG400 | 33.0-50.0 | 0.2 | 1.25 | -55~+85 | 50 | WR22 | 2.4mm |
