TAB Drop-in RF Isolator 3GHz 4GHz 5GHz 12GHz 18GHz

Inquire Now Next Product

Product Description

Frequency covers 80MHz~40GHz

Factory service with Fast lead time

OEM&ODM Service support

Model No.	Frequency (GHz)	Band Width (MHz)	Insertion Loss (dB.Max)	Isolation (dB.Min)	VSWR (Max)	Forward Power (W)	Size LWH(mm)	Connector Type
Model No.	Frequency (GHz)	Band Width (MHz)	Insertion Loss (dB.Max)	Isolation (dB.Min)	VSWR (Max)	Forward Power (W)	Size LWH(mm)	Connector Type
TWMTG0102B	0.13~0.18	4	0.4	23	1.2	300	50.850.815	TAB
TWMTG0102B	0.18~0.5	10	0.3	25	1.2	300	50.850.815	TAB
TWMTG0302	0.14~0.18	4	0.3	23	1.2	200	505218	TAB
	0.2~0.3	20	0.4	20	1.25
	0.4~0.6	70	0.3	23	1.2
	0.2~0.3	20	0.4	20	1.25
	0.3~0.6	70	0.3	20	1.2
TWMTG0402F	0.16~0.24	4	0.4	20	1.25	150	454513	TAB
TWMTG0402F	0.4~0.8	20	0.25	25	1.15	150	454513	TAB
TWMTG0402B1-100	0.3~0.4	5	0.3	23	1.2
TWMTG0402B1-100	0.4~1.0	20	0.3	23	1.2	150	354613	TAB
TWMTG0902B	0.7~1.0	30	0.3	23	1.2	30	20208.6	TAB
TWMTG0902B	960-1215	Full	0.5	18	1.3	30	20208.6	TAB
TWMTG102A1	0.35~0.4	10	0.3	23	1.2	60	25.425.410	TAB
	0.4~0.6	20	0.3	23	1.2
	0.8~1.0	30	0.2	25	1.15
TWMTG102A1-100	0.35~0.4	10	0.3	23	1.2	150	25.431.710	TAB
TWMTG102A1-100	0.8~1.0	30	0.2	25	1.15	150	25.431.710	TAB
TWMTG102K6C	1.5~1.8	25	0.4	20	1.25	20	10106	TAB
TWMTG102K6C	1.614-1.618	4	0.3	25	1.2	20	10106	TAB
TWMTG202B	1.5~4.2	100	0.3	23	1.15	30	19198	TAB
TWMTG202B	1.8~4.2	400	0.4	20	1.25	30	19198	TAB
TWMTG202D1	1.7~3.0	30	0.3	25	1.2	20	12.712.77.2	TAB
	1.7~3.0	70	0.3	23	1.2
	2.5~4.5	200	0.3	21	1.2
TWMTG202D1S	2.5~4.5	400	0.6	42	1.2	20	25.412.77.2	TAB
TWMTG402A	3.5~7.0	200	0.25	25	1.2	10	16239.5	TAB
TWMTG402A	3.5~7.0	600	0.3	23	1.2	10	16239.5	TAB
TWMTG402M	4.5~6.0	200	0.3	23	1.2	10	12.712.76.4	TAB
TWMTG502A	4.5~7.0	300	0.3	25	1.2	10	12209.5	TAB
TWMTG502A	4.5~7.0	600	0.4	23	1.2	10	12209.5	TAB
TWMTG502C1	5.0~8.0	300	0.3	25	1.2	10	12206	TAB
TWMTG502C1	5.0~8.0	600	0.3	20	1.25	10	12206	TAB
TWMTG602B	5.5~8.0	1000	0.3	23	1.2	10	8.912.075.6	TAB
TWMTG602B	5.725-7.125	Full	0.4	21	1.25	10	8.912.075.6	TAB
TWMTG702E	7~18	300	0.3	25	1.2	10	12.712.76.5	TAB
		1000	0.4	23	1.2
		2000	0.4	20	1.25
TWMTG902B	5.5~16	300	0.3	25	1.2	10	8.9157.8	TAB
TWMTG902B	16~20	1000	0.4	20	1.25	10	8.9157.8	TAB
TWMTG902E	7~10	500	0.4	23	1.2	10	995.5	TAB
TWMTG902E	10~18	1000	0.4	20	1.25	10	995.5	TAB
TWMTG902BS	7.0~18	500	0.6	50	1.25	10	17.8157.8	TAB
TWMTG1302C	9.0~16	300	0.3	25	1.2	10	9145.2	TAB
TWMTG1302C	10~18	4000	0.5	20	1.25	10	9145.2	TAB
TWMTG1402	7.0~1.0	500	0.4	20	1.25	5	612.77.2	TAB
TWMTG1402	10~18	1000	0.4	20	1.25	5	612.77.2	TAB
TWMTG1402A	17~22	1000	0.5	20	1.25	5	6.3512.74.5	TAB
TWMTG1402A	22~32	2000	0.6	18	1.3	5	6.3512.74.5	TAB
TWMTG2030A-W	26~36	2000	0.6	18	1.3	5	121512.8	TAB

New products always update under line and not always online in time, if you can not find what you want above.please contact us directly.we will reply very fast.

Tags: Drop-in isolator , TAB RF Isolator, 5G TAB Isolator, 4G TAB ISolator, 3G Isolator, Stripline Isolators, 5G Drop-in isolator , RF Isolators, Coaxial Isolators
