SMA to SMA Straight RF Adapter 18GHz 26.5GHz 50ohm
SMA series adapter
Frequency up to 26.5GHz
Factory supply with fast delivery
Welcome to send inquiry
Adapters SMA
SMA Precision coaxial connector for microwave applications.the maximum frequency is
26.5GHz.
• Design in accordance with: MIL-STD-348
Standard materials and finish
• Center conductor:beryllium copper,gold plated
• Insulator:PTFE
• Outer conductor:Stainless steel,Passivated
Electrical Characteristics
• Characteristic Impedance:50Ω
• Frequency range:DC-26.5GHz
• VSWR: DC-18GHz,1.10:1 max
18-26.5GHz,1.2:1 max
• Insulation resistance: 5000MΩ min
• Test voltage:1000V
Mechanical
• Coupling torque:1.69N•m max
• Mating cycles: 500cycles min
Environmental
• Temperature range: -50℃～+125℃
