Home > Products >> Coaxial Fixed Attenuator >> 1W 2W Coaxial Fixed Attenuator

2W RF Coaxial Attenuator N male to female 3GHz 4GHz 1dB 2dB 3dB 5dB 6dB 10dB 15dB 20dB 30dB 40dB

TWAN-2-3-XX
Frequency 0-3GHz
SMA,N,BNC,TNC,7/16,4.3/10 connector support
Attention range from 1-40dB,Customized support
Factory supply with fast delivery
welcome to send inquiry

  • Product Description

Professional Factory service onCoaxial Attenuator,Termination load,power range from 1-2000W with frequency up to 67GHz.

1.High quality with fast delivery

2.Professional R&D team

3.OEM&ODM service support

4.Competitive price

As the connector support SMA/N/BNC/TNC/DIN/4.3-10 optional

welcome to send inquiry,we will do our best to support


Fixed Attenuators are placed in signal paths to reduce power transmission and are set at a fixed attenuation by symmetrical resistive networks that follows a T, L or Pi configuration. Their configuration can either be in waveguide, in surface mount or coaxial, and depending on their application, they can either be directional or bidirectional.


Applications:

Attenuators are generally used in radio, communication and transmission line applications to weaken a stronger signal.


50ohm DC-3/4/6GHz, 2W N Fixed Attenuator Technical Specifications:
NORMINAL IMPENDANCE50ΩFREQUENCY RANGEDC to 3GHz
VSWR3GHz≤1.2
POWER RATING2W
TEMPERATURE RANGE-55°C to +125°C
Dimensions:φ20*60 mm
Attenuation1,2,3,4,5,6,7,8,9,10,15,20,30.40dB available, and 1-9dB±0.8dB,10-30dB±1dB

2W coaxial attenuator N male to N female 3Ghz 6Ghz 8Ghz 10GHz 12Ghz 18GHz 1dB 2dB 3dB 4dB 5dB 6dB 7dB 8dB 9dB 10dB 15dB 20dB 30dB 50ohm
